GNSSconfiguration
|
Number of channels
|
220
|
|
BDS
|
B1,B2,B3
|
|
GPS
|
L1C/A,L1C,L2C,L2E,L5
|
|
GLONASS
|
L1C/A,L1P,L2C/A,L2P,L3
|
|
GALILEO
|
GIOVE-A,GIOVE-B,E1,E5A,E5B
|
|
QZSS
|
L1C/A,L1 SAiF ,L2C,L5
|
|
Positioning output frequency
|
1Hz~50Hz
|
|
Differential support
|
CMR,RTCM2.X,RTCM3.0,RTCM3.2
|
|
Static format support
|
GNS, Rinex dual format static data
|
|
RTK positioning accuracy |
Plane: ±(8+1×10-6D) mm(D is the distance between the measured points)
Elevation: ±(15+1×10-6D) mm
(D is the distance between the measured points)
|
|
Static positioning accuracy |
Plane: ±(2.5+0.5×10¯6D) mm
(D is the distance between the measured points)
Elevation: ±(5+0.5×10¯6D) mm
(D is the distance between the measured points)
|
|
DGPS positioning accuracy
|
Plane accuracy: ±0.25m+1ppm;
Elevation accuracy: ±0.50m+1ppm
|
|
Initialization time
|
<10 seconds
|
|
Initialization reliability
|
＞99.99%
|
|
Built-in communication |
network
|
Built-in 4G full Netcom network communication
|
|
WiFi
|
802.11b/g access point and client mode, can provide WiFi hotspot service
|
|
Bluetooth
|
Built-in Bluetooth
|
|
Built-in transceiver
|
|
Power
|
0.5w/2w
|
|
frequency band:
|
405MHz-470MHz
|
|
Protocol
|
TrimTalk405s,TrimMark3,PCC EOT
|
|
User Interface |
panel
|
Single button
|
|
Indicator light
|
Three indicator lights
|
|
Electrical physical properties |
battery
|
High-capacity lithium battery 3400mAh/piece (2 pieces), removable Single battery network mobile station continuously working for
more than 10 hours
|
|
Input voltage
|
DC 6~28VDC, with over-discharge protection
|
|
size
|
Φ129mm×112mm
|
|
weight
|
≤1kg
|
|
material
|
Shell is made of magnesium alloy material
|
|
Environmental characteristics
|
Dust and water release
|
P68, can resist temporary immersion under 2 meters water, completely prevent dust from entering
|
|
Anti-fall
|
Resistance to natural drop of 3 meters
|
|
Operating temperature
|
-45℃~75℃
|
|
Specification
|
|
|
|
System
|
model
|
H5
|
|
operating system
|
Android 8.1
|
|
CPU
|
2.0 GHz eight-core processor
|
|
Memory
|
3GB RAM
|
|
Storage
|
32GB
|
|
Communication
|
Network
|
TDD/FDD-LTE 4G
|
|
WiFi
|
802.11b/g access point and client mode, can provide WiFi hotspot service
|
|
Bluetooth
|
V2.1+EDR/V3.0+HS/V4.1
|
|
NFC
|
Support NFC IGRS
|
|
USB
|
Mini USB, supports OTG
|
|
Electrical |
Battery
|
7.4V, 3400mAh
|
|
Battery life
|
12 hours
|
|
Charging
|
< 4 hrs for full charge
|
|
Physical
|
size
|
206mm×85mm×40mm
|
|
Weight
|
470g
|
|
Operating temperature
|
-30℃ ~ +60℃
|
